Tos W100A 4" Table Type Horizontal Boring Mill
Have one to sell?
ConditionUsed
1 available
4" Tos Model W100A Table Type Horizontal Boring Mill, #50 Taper, 49" x 49" Table, Facing Head, Tailstock
Diameter Of Spindle: 4"
Taper Of Spindle: #50 Std.
Spindle Travel: 35-1/2"
Working Surface Table: 49" X 49"
Cross Table Travel:63"
Max Distance Spindle To Table:44"
Saddle Travel:49"
Spindle Speeds (23): 7.1 To 1120 Rpm
Faceplate Speeds (16): 7.1 To 224 Rpm
Boring Feed Ranges (32):.0008 To .47 Ipr
Milling Feeds (18):7 To 35.4 Ipm
Rotary Table Feeds (18): .98 To 55 Ipm
Rapid Traverse Rate:110 Ipm
Maximum Weight Of Work Piece: 6,600 Lbs.
Weight :34,000 Lbs
Built In Rotary Table 49" x 49", 24" Facing Head, Tail Stock
