330 TON STAMTEC S2-300 STRAIGHT SIDE DOUBLE CRANK PRESS

2000 STAMTEC S2-300 Press Room, SSDC | Gulf Coast Machinery (1)

2000 STAMTEC S2-300 Press Room, SSDC | Gulf Coast Machinery (2)

2000 STAMTEC S2-300 Press Room, SSDC | Gulf Coast Machinery (3)

2000 STAMTEC S2-300 Press Room, SSDC | Gulf Coast Machinery (4)

2000 STAMTEC S2-300 Press Room, SSDC | Gulf Coast Machinery (5)

2000 STAMTEC S2-300 Press Room, SSDC | Gulf Coast Machinery (6)

2000 STAMTEC S2-300 Press Room, SSDC | Gulf Coast Machinery (7)

2000 STAMTEC S2-300 Press Room, SSDC | Gulf Coast Machinery (8)

2000 STAMTEC S2-300 Press Room, SSDC | Gulf Coast Machinery (9)

2000 STAMTEC S2-300 Press Room, SSDC | Gulf Coast Machinery (10)

2000 STAMTEC S2-300 Press Room, SSDC | Gulf Coast Machinery (11)

2000 STAMTEC S2-300 Press Room, SSDC | Gulf Coast Machinery (12)

2000 STAMTEC S2-300 Press Room, SSDC | Gulf Coast Machinery (13)

2000 STAMTEC S2-300 Press Room, SSDC | Gulf Coast Machinery (14)

2000 STAMTEC S2-300 Press Room, SSDC | Gulf Coast Machinery (15)

2000 STAMTEC S2-300 Press Room, SSDC | Gulf Coast Machinery (16)

2000 STAMTEC S2-300 Press Room, SSDC | Gulf Coast Machinery (17)

2000 STAMTEC S2-300 Press Room, SSDC | Gulf Coast Machinery (18)

2000 STAMTEC S2-300 Press Room, SSDC | Gulf Coast Machinery (19)

2000 STAMTEC S2-300 Press Room, SSDC | Gulf Coast Machinery (20)

2000 STAMTEC S2-300 Press Room, SSDC | Gulf Coast Machinery

Overview

Type:

Press Room, SSDC

Manufacturer:

STAMTEC

Model:

S2-300

Condition:

Used - Good

Year:

2000

Stock #:

1394

Status:

For Sale

Serial #:

591029

Description

330 TON STAMTEC S2-300 STRAIGHT SIDE DOUBLE CRANK PRESS, 98.43" LR x 55.12" FB Bed, 10" Stroke, 30.12" SH, 30-60 SPM, 44" Windows

Specifications

Capacity (US Tons) 330 Tons
Bed Area 98.43" LR x 55.12" FB
Stroke Length 10.12"
Shut Height 30.12"
Speed 30-60 SPM
Windows 34.75" wide x 27.50"H
Ram Adjustment 8.27"
Working Height To Top of 7" Bolster 39.37"
Approx. Weight 145,000 LBS
Approx Dimensions (Top Of Press) 150"LR x 118"FB x 180"H
480/3/60,
146/73 Max Amps

Equipped With

S2 SERIES 2-POINT STRAIGHT SIDE PRESS: The Stamtec S2 two-point straight side press (a.k.a. double crank press) is designed for stamping large parts or ones that require a large bed area to accommodate progressive or transfer dies. Oftentimes, these types of operations require high tonnage, high flywheel energy, maximum frame or bed rigidity, or some combination thereof. The path of the slide is guided by eight full-length, ninety-degree gibs with nickel-bronze wear plates, offering maximum control, a high degree of accuracy and ease of adjustment.

* Video Available, Disassembled for shipping-
*Preliminary equipment descriptions are intended only as a guide, items of importance should be verified by the buyer-
